CE Certificate High Speed High Table Automatic Strapping Machine for Carton Case Boxes
Description
Basic Info.
Model NO. | Q8 |
Strapping Mode | Welding Type |
Packaging Material | Plastic |
Driven Type | Electric |
Structure | Basic Type Strapping |
Power | 1000W, 10A |
Cereficate | CE |
Strap Width | 9mm, 12mm |
Tension | 10-400n |
Loading Weight | 80kgs |
Arch Size | 800*600mm |
Power Supply | 220V 50Hz 1phase |
Strapping Speed | 50-53 Straps/M |
Material Thickness | 0.35-0.65mm |
Table Height | 750 mm |
Transport Package | Wooden Case |
Trademark | sunpack |
Origin | China |
HS Code | 8422400090 |
Production Capacity | 100sets One Month |
Product Description
CE Certificate High Speed High Table Automatic Strapping Machine For Carton Case BoxesProduct Description
Q8 series automatic strapping machine is suitable for regular objects and all kinds of cartons. The biggest characteristic of this series machine is that it can use 0.35mm thick PP strap, which saves a lot of consumables cost for users.
Features:
Manual and Auto model operationHigh speed automatic strapping machine can make 1.5 seconds/strapLoop ejecting function and refeed functionRigid structure designBuilt for 24 hours of continuous operationTension adjustment Very easy from the control panelEasy strap loading and unloadingCan be used for 5mm strap, save your costAutomatic belt piercing device, detect whether there is any belt, when there is no belt, it will automatically shoot the remaining belt from the left interface and the movement quickly
Machine technical parameter
Product name | fast speed strapping machine | fast speed strapping machine | fast speed strapping machine |
item no | Q8 | Q8D | Q8S |
motor | VTV DC motor | DUNKER DC motor | DUNKER Servo motor |
material | PP strapping band | ||
material size | width 9,12mm,thickness 0.35-0.65mm | ||
arch size(W*H) | 600 x 500mm,800*600mm,(Other sizes can be customized) | ||
packing size | Max 600 x 450mm Min100 x50mm (W600*H500) | ||
power | 220V,50HZ,500W | ||
control system | PCB(PLC can be customized) | ||
strapping speed | 1.5second/strap (W800*500) | ||
Tension | 10-400N | ||
Machine size | 1255*700*1400 (W600*H500) | ||
table height | 750-800mm | ||
Weight | 140KG | ||
Shell material | Carbon steel spray, 304 stainless steel can be customized |
Product advantages
Related Products
According to the needs of customers, there are frames in different states, table top structures, and frame sizes
Company Profile
Xutian (Sunpack) was established in 1997 with the goal of providing the best strapping machine in the industry at competitive prices.Xutian (Sunpack)is a group company with 3 branches located in Taizhou, Wenzhou and Dongguan. We dedicate to end of line package development for years. We have more than 30 staff in our RND department . We carry banding machine, strapping machine, pallet wrapper, case sealer and manual strapping tool in our range.Our goal is to make every customer completely satisfied with the best packaging machinery and services through continuous improvement and employee involvement.We believe that innovation is key to our success. Through a firm commitment to research and development, we have earned a reputation for being at the forefront of packaging innovation. We provide our customers with advanced solutions that increase production efficiency, improve load integrity and reduce operating costs. Over the years, we've continuously refined our existing products and created new ones to take advantage of evolving technologies and to meet our customers' ever-changing needs.We appreciate your interest in our company and will be in touch with you as soon as possible to discuss your specific needs.
Exhibitionpacking & shipping
Our Service
1.Fast parts delivery
Within 3 days to deliver required parts
2.Fast response
Within 24 hours to give email reply or calling-back and solve the claim
3.24 hours in hall service
Within 24 hours to arrive in cusotmer's location
4.Agent call-in help
Local agents could help for Emergency cases
5.OEM SERVICE
OEM design for all customers
